Web Height 1500mm H Beam Assembly Machine 16mm Auto Manual Welding

Product Categories
Dongtai Yaoqiang machinery Co.,Ltd
Contact Now

Web Height 1500mm H Beam Assembly Machine 16mm Auto Manual Welding

  • 1
  • 2
  • 3

Brand Name : Yaoqiang

Model Number : YQPJ1500

Certification : CE ISO

Place of Origin : WUXI,CHINA

MOQ : 1 SET

Price : 45000

Payment Terms : L/C, T/T

Supply Ability : 10 SET/MONTH

Delivery Time : 20 DAYS

Color : Blue

Main drive roll speed : 350-6000mm/min

Main drive roll engine power : 7.5KW

Straightening hydro-cylinder lift length : 200mm

Web height : 1500mm

Flange width : 200-800 mm

Contact Now

Yaoqiang Factory produces fully automatic steel profile welding and production machine--SAW arc TIG MIG mag H Beam Automatic Welding Machine.
Professional and effecient equipments to help you in H beam, pipe-flange, pipe-elbow and etc. Welding and fabrication.

Assembly/welding/straightening integrated machine is Yaoqiang's self patent product which puts assembling, gantry welding and hydraulic straightener in one.
Feed material into abdominal cavity, you only need to press the button, the machine can work till the material formed into finished profile in one time. During the process, labor interference is reduced. The production efficiency is improved highly and equipment cost and manpower cost reduced, and equipment installation room also saved. It is the most efficient steel H beam and T beam production equipment.

Web Height 1500mm H Beam Assembly Machine 16mm Auto Manual Welding

Specification:

Work piece flange width / thickness 200-600mm / 6-20mm
Work piece web highness / thickness 350-1500mm / 6-14mm
Main drive roll diameter Φ 250mm
Main drive roll speed 350-6000mm/min
Main drive roll speed adjust AC frequency no rate speed adjustment
Straightening wheel diameter Φ 180mm
Straightening hydro-cylinder lift length 200mm
Straightening hold wheel diameter Φ 380mm
Main drive roll engine power 7.5KW
Upper roller wheel diameter Φ 160mm
Upper roller lift hydro-cylinder distance 1350mm
Model No. YQPJ1000 / YQPJ1200 / YQPJ1500

Web Height 1500mm H Beam Assembly Machine 16mm Auto Manual Welding

Model web height web thickness welding and straightening speed flange width flange thickness overall power
YQPJ1000 1000mm 6-16mm 0.35-3m/min 200-800mm 6-20mm 13.4kw
YQPJ1200 1200mm 6-16mm 0.35-3m/min 200-800mm 6-20mm 13.4kw
YQPJ1500 1500mm 6-16mm 0.35-3m/min 200-800mm 6-20mm

13.4kw

Quality warranty and after-sales service
1, Technical Services
(1) Timely, prompt, high-quality, comprehensive after-sales service.
(2) Easy access of spare parts and technical advice;
2, Quality assurance
(1) 12 months warranty, free replacement if any problem, except for damage from the irresistible natural disasters and man-made factors.
(2) Reasonable maintenance charge after warranty, to ensure favorable technical services, consumables and spare parts;
